5.3 Chuck Control Connections
Table 5-1 Terminal TB1
1 (+) Chuck DC
2 (-) Chuck DC
Table 5-2 Connector - J4
1,2 Lockout Supply Relay Contacts
3,4,5 Part Released Signal Relay Contacts
6,7,8 Current Sense Relay Contacts
Table 5-3 Connector - J5
1 50K Ohm Variable Potentiometer
2 GND
3 Release Lamp
4 Variable Lamp
5 Full Lamp
6 Residual Lamp
7 LED Common
8 Lockout Option
9 Variable Pushbutton
10 Full Pushbutton
11 Residual Pushbutton
12 Release Pushbutton
13 GND (Pushbutton Common)
14 +5V
15 # of Release Pulses
16 Lamp Common
Adjustments
Number of Release Pulses (1-16) - Set to 8 pulses at factory (See Release section 4.5 page
4-3)
