Micro module still controls
devices even after factory
reset
The responder’s link was not
removed prior to Micro
module factory reset (called a
half-link)
Remove responder from Micro module
Stuck/Disabled Button
If Micro module’s buttons are not responding, they may have been disabled due to a stuck button. If any button is
pressed during power-up, or after power-up any Micro module button is pressed for about four minutes, Micro
module engages stuck button mode and automatically disables all button actions. All buttons will remain disabled
until next power cycle.
To re-enable buttons, ensure buttons are not being pressed, turn off breaker supplying power to Micro module and
turn it back on. Micro module buttons should function again. Additionally, check Micro module’s installation location
for any obstacles that could be pressing the buttons on Micro module’s face and causing stuck button mode.
Phase Bridge Detect Beacon/RF Range Test
Micro module automatically bridges the electrical phases in your home (via communications with other dual-band
devices on the “other phase”). This is only important in 2-phase homes with powerline-only INSTEON products or
buildings with both 2- and 3- phase circuits. The phase bridge detect beacon can also be used as an RF range test to
see if your devices are within communication range. You will need at least one other INSTEON dual-band device
installed.
1) Press and hold Set button until it beeps
LED will start blinking green
2) Press and hold Set button until it beeps again
LED will start blinking red
3) Press and hold Set button until it beeps a third time
LED will start blinking green
4) Slowly tap Set button twice
LED will continue blinking green
5) Press and hold Set button until it beeps
Micro module will start beeping once per second
LED will turn solid green
6) Check the LED behavior of other dual-band devices
•
If the other dual-band device is blinking
green, it is on the other phase:
Device provides a phase bridge to Micro module
•
If the other dual-band device is blinking red, it is on the same phase:
Device does not provide a phase bridge to Micro module
Relocate if necessary (and practical)
•
If the other dual-band device is not blinking:
Device is not within RF range of Micro module so it does not provide a phase bridge
Relocate if necessary (and practical)
•
RF range test: if LED is blinking:
Device is within RF communication range
•
RF range test: if LED is not blinking:
Device is not within RF communication range
7) Tap Set button
Micro module will stop beeping
Other device LEDs will stop blinking
If you have tried these solutions, reviewed the owner's manual, and still cannot resolve the issue you are having visit
or call INSTEON Support Line at 866-243-8022.
