Dual Momentary Wall Switch
Adjust Local Settings
Change LED Brightness (or turn it off)
Default = 50% brightness level
1) Press and hold Set button until it beeps
LED will start blinking green
2) Press and hold Set button until it beeps again
LED will start blinking red
3) Press and hold Set button until it beeps a third time
LED will start blinking green
4) Tap Set button once
LED will start double-blinking green
5) Press and hold Set button until it beeps
LED will turn green (at brightness of connected load)
6) Press and hold Micro module on/off buttons to brighten or dim LED to desired brightness
7) Tap Set button
Micro On/Off will double-beep and return to ready mode
Error Blink
Default = enabled
This setting is only adjustable via software or a central controller. Micro module LED will blink red once if one or more
responders do not acknowledge a message and will blink green once if all responders are successful.
Blink on Traffic
Default = disabled
This setting is only adjustable via software or a central controller. Micro module LED will blink red if it detects noise
that could disrupt communication.
Beep on Button Press
Default = disabled
Connected load/responders
Dual momentary switch Tap Press and hold Double-tap LED
Top
Up/On
(ramped)
Up
Brighten
until release or 100%
(dimmable responders only)
Up/On
(instant)
Green
Bottom
Down/Off
(ramped)
Down
Dim
until release or off
(dimmable responders only)
Down/Off
(instant)
Red
