Page 15 of 21 2444-222/2444-422/2444-522 - Rev: 2/24/2014 9:10 AM
3) Send the X10 address 3 times (with or without commands)
Example: A1-AOFF-A1-AOFF-A1-AOFF or A1-A1-A1-AOFF
Micro module will double-beep and LED will stop blinking
4) Test by sending X10 on and off commands
Micro module will not respond
Specifications
General
Product name Micro Open/Close
Brand / manufacturer INSTEON
Manufacturer product number
2444-222 (US)
2444-422 (EU)
2444-522 (AUS/NZ)
UPC
813922012767 (US)
813922012774 (EU)
813922012774 (AUS/NZ)
Warranty 2 years, limited
INSTEON
INSTEON Controller and responder
Maximum links / scenes 400
Status LED
Green when load is open, red when load is closed
Blinks red once when responder does not acknowledge/blinks
green once if all responders acknowledge (can be disabled via
software)
Blinks red or green during setup
Blinks red to indicate traffic (must be enabled via software)
Beep on button press
Beeps when button is pressed or connected switch is tapped
(must be enabled via software)
LED brightness Adjustable, from off to bright
Local control Yes
Commands supported as controller
On Off
Fast-on Fast-off
Begin brighten Begin dim
End brighten End dim
Commands supported as responder
Open (on) Close (off)
Begin raise (brighten) Begin lower (dim)
End raise (brighten) End lower (dim)
Beep
Software Configurable Yes
RF Range
Up to 50 meters (150 feet) open air*
*Range may vary due to local interference/building construction
