I-View FE-5MIPN 5-Megapixels IR Vandal Proof Dome IP Camera User Manual
Page 10

10
I/O Port
Standard: Audio in (2Vp-p); Audio out (30mW/600
Ω); DC power in, RJ-45 (LED
indicates power /linking status).
Option: Alarm in/out x1; TV out, Reset button (FE-5MIPN-F01-F),
Surge Protector
Built in TVS 2,000V Common Mode Voltage type lightning protection, surge protection and
voltage transient protection.
Lens & IR Cut
Lens: f=1.05/F2.8
IR Cut: Built on removable IR-cut filter for day & night function.
Storage
Micro SD slot for SD/SDHC card storage; Support Pre-recording and Post recording; Network
failed start recording on SD card, Backup/Restore to device configuration file, Backup, Upload
data to FTP/SMTP sever.
Management
Time management: Manual Time Setting; Time Server and NTP support; Real Time Clock.
Event management: Events triggered by motion detection or sensor configured by schedule.
Event notification: Notify to FTP, email, PTZ camera or Digital output triggered.
Update: Support Firmware update.
Browse
I.E. 7.0 above; Safari Browser, Fire Fox and Chrome V3.0 above with plug in.
Housing
Vandal-proof IK10-rated Aluminum housing
Dimension/Weight
ø
104mm (L) x 58 mm (H) / 0.38Kg.
Operation
Power: Maximum 3 W; PoE IEEE 802.3af Class 3; DV12V
Temperature: Temperature -10°C ~ 50°C; Humidity 20% ~ 80% RH.
