I-View DM-5MIPN30 5-Megapixels IR Vandal Proof Dome IP Camera - Manual (Page 9)

9
1-2.
Product Specification
DM-5MIPN30 Series
System
Platform: TI DM368 SoC CPU; Linux Embedded O.S.
Image Device
1/2.5" 5 M pixels (2592x 1944 pixels) progressive CMOS sensor.
Video Setting
Compression: Video: 0.1M ~ 12M bits/sec (CBR/VBR/LBR configurable) H.264
HP/MP/BP, M-JPEG; Audio: G.711
μ-low/a-low Codec
Resolution: Main Streaming: 2592Ч1920, 2048Ч1536, 1920Ч1080, 1280Ч720. Sub
streaming: 320×288, 320*240
Frame Rate: 5-Mega: 10 fps; 3-Mega: 20 fps; 1080p: 30 fps @ H.264/M-JPEG Mode; Frame
rate can be adjustable by user.
Streaming: Multi-Stream H.264 Base/Main/High Profile and Motion JPEG video streaming
Control: Brightness, Contrast, Saturation, Sharpness, Exposure, Motion detection, Mirror,
Shutter, Privacy mask, Flickerless, Noise reduction, IRIS, AES, AWB, AGC, BLC,
D-WDR, ROI, Audio gain, Alarm in/out
Color: 0.5 Lux 1/F1.2 B/W: 0 Lux. (IR LED on)
D-WDR: 70dB
Overlay: Text / Time Stamp
Audio Setting
μ-Low/ a-Low G.711 audio encoding and decoding; 2-way audio.
External Microphone input; Speaker output.
2Vp-p audio input and audio output with 600
Ω impedance.
Network
Protocol: HTTP, HTTPS, TCP/ IP, IPv4, IPv6, UDP, SMTP, FTP, DHCP, DDNS, NTP,
DNS, SNMP, RTSP, RTP/RTCP, Bonjour, PPPoE, QoS, UPnP, IGMP; uPnP and 802.1x.
Interface: 10BASE-T/100 BASE-TX; Wi-Fi (Via USB optional)
Compatible: Onvif compliant.
