10
I/O Port
Standard:
Audio in (2Vp-p); Audio out (30mW/600
Ω); DC power in, RJ-45
(LED indicates power /linking status).
Full function:
Alarm in x1; Alarm out x1; TV out, Reset button, Video out, SD Card
slot. (DM-5MIPN30-Fxxxx-F)
Option:
USB for Wi-Fi device
Surge Protector
Video:
Peak Inverse Blocking Voltage: VPIB= 100V; Peak Pulse Current:
Ipp=44A; Clamping Voltage: 10V @ Ipp= 5A.
Power:
Maximum Energy: 3.6J @10/1000µs; Clamping Voltage:
16.8KA(1-Time)/8.4KA(2-Times) @8/20µs (1 Time); Insulation Resistance:
≧
10000M
Ω.
Lens & IR Illuminators
Lens:
f=3
〜9 mm/ F1.2〜F2.3 (DM-5MIPN30-F0309 & DM-5MIPN30-F0309-F );
f=2.8
〜12 mm/ F1.2〜F2.8 (DM-5MIPN30-F0312 & DM-5MIPN30-F0312-F );
f=
4mm; 6mm, 8mm, 12mm/ F1.8 (Optional) (DM-5MIPN30-F04/06/08/12).
IR Cut:
Built on removable IR-cut filter for day & night function.
IR Illuminators
: 30 pieces 14
μ IR LED Illuminators.
Storage
Micro SD slot for SD/SDHC card storage; Support Pre-recording and Post recording; Network
failed start recording on SD card, Backup/Restore to device configuration file, Backup, Upload
data to FTP/SMTP sever.
Management
Time management:
Manual Time Setting; Time Server and NTP support; Real Time Clock.
Event management:
Events triggered by motion detection or sensor configured by schedule.
Event notification:
Notify to FTP, email, Samba server or Digital output triggered.
Update:
Support Firmware update.
