116
9. Technical data
Model number TVIP31001
Image sensor 1/4" progressive scan CMOS sensor
Camera type Color
Resolution 1280x720, 640x480, 320x240, 160x120
Pixels (total) 1280x720
Pixels (effective) 1280x720
Lens 4.0 mm, F1.5
Horizontal angle of view 53°
Digital zoom 10x
Minimum illumination (color) 0.5 lux
Image compression H.264, MPEG-4, MJPEG
Frame rate H.264: 25 frames/sec @ 640x480
H.264: 25 frames/sec @ 1280x720
MPEG-4: 25 frames/sec @ 640x480
MPEG-4: 15 frames/sec @ 1280x720
MJPEG: 25 frames/sec @ 640x480
MJPEG: 25 frames/sec @ 1280x720
Number of parallel streams 4
Electronic shutter control 1 – 1/17800 sec.
White balance Yes
Amplifier control 0–9 dB
Backlight compensation BLC, WDR
Motion detection 3 zones
Pre-alarm/post-alarm memory Yes, 7 pre-alarm / 7 post-alarm images, 7 sec. pre-recording, 7 sec. post-recording
Image overlay Date, camera name, private zone
Integrated memory MicroSD slot SD/SDHC, max. 32 GB, class 6
Alarm input (NO/NC) 1
Switching output 1 (max. 12 V DC @ 100 mA)
Alarm notification
E-mail / FTP / HTTP notification / switching output / network drive /
microSD card
Supported browsers Mozilla Firefox, Safari, or Internet Explorer 6.x and higher
Supported software Eytron VMS
Network access RJ-45 Ethernet 10/100 Base-T
Network protocols
Bonjour, TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, DNS, NTP, UPnP,
RTSP, RTP, HTTP, TCP, UDP, 3GPP/ISMA RTSP
PoE (Power over Ethernet) PoE IEEE 802.11af
Encryption HTTPS
Access protection IP address filter, user name, password, 3 authorization levels
Power supply 12 V DC
Current consumption Max. 1 A
Operating temperature 0°C – 50°C
Dimensions (Hx ) 94 x 145 mm
Certifications CE, RoHS, WEEE, REACH
