Page 40: Pre l iminar y
28
Vidikron Vision 70 Series Owner’s Operating Manual
PRE
L
IMINAR
Y
RS-232 Controller
Connection
Connect a PC or home theater control/automation system (if present) to the RS-232 port on
the Vision 70; see Figure 3-12. Use a standard, 4-wire RJ-11 telephone cable, wired
straight-through.
For more information about using this connection, refer to Serial Communications on
page 65.
Figure 3-12. RS-232 Control System Connection
➤
S-VID /
S-VID
DTV Source,
DVD Player, VCR,
Satellite Receiver
etc.
