RGB Connections: Connect your personal computer or other RGB source (DVD player or HD
set top box) to the COMP 2/RGB input; see Figure 3-9. You can use the included
DB15HD-to-5 x BNC cable if your RGB source has a 15-pin, VGA-type connector.
Figure 3-9. RGB Connections
The Vision 70 supports computer resolutions of 1024x768, 800x600 and
640x480.
Note
S-VID /
S-VID
S-VID /
S-VID
DVD Player or
HD Set Top Box
Green Blue Red Horiz Vert
Green Blue Red Horiz Vert
Personal Computer
