Generator assembly parts list – United States Stove Company VFZC32L User Manual
Page 27
KEY
PART #
DESCRIPTION
QTY.
1
24610
BURNER PLATE
1
2
24611
CONTROL BRACKET
1
3
81193
CONTROL VALVE (NATURAL)
1
81194
CONTROL VALVE (L.P.)
1
4
83251
10-24 x 1 SL ROD
2
5
83244
10-24 KEP NUT
2
•
83343
#10 X 1/2 HX HD SCREW
10
6
89831
BURNER/CONTROL FITTING
1
7
89834
1/4" TUBE, BURNER
1
8
89838
1/4 CC X 3/8-27 FITTING
1
9
89839
1/4 COMPRESSION NUT
1
10
89840
1/4 COMPRESSION SLEEVE
1
11
24612
PILOT BRACKET
1
12
89900
"O.P. AMERICA" NAT. PILOT
1
89873
"O.P. AMERICA" L.P. PILOT
1
•
83437
10-3/4 HX HD SCREW (TO MOUNT PILOT)
2
13
89841
3/16 COMPRESSION NUT
1
14
89842
3/16 COMPRESSION SLEEVE
1
15
89853
#50 NATURAL BURNER ORIFICE(FRONT)
1
89854
#56 L.P. BURNER ORIFICE (FRONT)
1
16
89853
#50 NATURAL BURNER ORIFICE(REAR)
1
89854
#56 L.P. BURNER ORIFICE (REAR)
1
17
24613
BURNER (PAINTED)
2
18
89874
LOG SET (CONSISTS OF 4 PIECES)
1
a
89874-1
FRONT LOG
-
b
89874-2
REAR LOG
-
c
89874-3
RIGHT TWIG
-
d
89874-4
LEFT TWIG
-
19
89856
3/16" LOXIT FITTING
1
•
86318
16GA WIRE LINK
1FT.
20
89855
PILOT TUBE
1
•
89728
GAS FLEX PIPE
1
GENERATOR ASSEMBLY PARTS LIST
27
• = NOT SHOWN
