P LASMA M ONITOR Ⅵ Ⅵ Ⅵ †
57
25. AUTO PICTURE Select
Function
The external control equipment switches the
AUTO PICTURE of the display on and off.
Transmissin Data
CFH UA1 UA2 57H 02H DATA00 DATA01 CKS
DATA00
01H : AUTO PICTURE ON
02H : AUTO PICTURE OFF
DATA01
01H : MODE 4X3
02H : MODE 16X9
03H : MODE 16X9!
ACK
6FH UA1 UA2 57H 02H DATA00 DATA01 CKS
DATA00
01H : AUTO PICTURE ON
02H : AUTO PICTURE OFF
DATA01
01H : MODE 4X3
02H : MODE 16X9
03H : MODE 16X9!
26. RESET
Function
The external control equipment resets the user
adjustment items of the display.
Transmissin Data
0FH UA1 UA2 54H 01H DATA00 CKS
DATA00
00H : ALL NORMAL
01H : RASTER NORMAL
02H : VISUAL NORMAL
ACK
2FH UA1 UA2 54H 01H DATA00 CKS
DATA00
00H : ALL NORMAL
01H : RASTER NORMAL
02H : VISUAL NORMAL
* The operation is the same as when the remote
control key has been entered.
27. COLOR SYSTEM Select
Function
The external control equipment selects the color
system settings of the display.
Transmission Data
CFH UA1 UA2 5CH 01H DATA00 CKS
DATA00
01H : NTSC3.58
02H : NTSC4.43
03H : PAL
04H : SECAM
96H : AUTO
ACK
6FH UA1 UA2 5CH 01H DATA00 CKS
DATA00
01H : NTSC3.58
02H : NTSC4.43
03H : PAL
04H : SECAM
96H : AUTO
28. INPUT MODE Request
Function
The display returns the current status for input
mode requests of the external control equip-
ment.
Transmission Data
0FH UA1 UA2 41H 00H CKS
ACK
6FH UA1 UA2 41H 01H DATA00 CKS
DATA00 : Input Select
01H : Video
02H : RGB1
03H : RGB2
04H : RGB3
05H : HD/DVD
0FH : SCART
29. SCREEN MODE Request
Function
The display returns the current status for screen
mode requests of the external control equip-
ment.
Transmission Data
0FH UA1 UA2 42H 00H CKS
ACK
6FH UA1 UA2 42H 01H DATA00 CKS
DATA00
02H : STADIUM
03H : ZOOM
04H : NORMAL
05H : FULL
Appendix
30. VIDEO ADJ Request
Function
The display returns the current status for video
adjustment information requests of the exter-
nal control equipment.
Transmission Data
0FH UA1 UA2 45H 00H CKS
ACK
6FH UA1 UA2 45H 0CH DATA00–DATA0B CKS
DATA00 : RED Gain
E0H : -32
|
FFH : -1
00H : 0
|
20H : +32
DATA01 : GREEN Gain
E0H : -32
|
FFH : -1
00H : 0
|
20H : +32
DATA02 : BLUE Gain
E0H : -32
|
FFH : -1
00H : 0
|
20H : +32
DATA03 : COLOR Gain
EAH : -22
|
FFH : -1
01H : 0
|
16H : +22
DATA04: TINT Gain
EAH : -22
|
FFH : -1
01H : 0
|
FFH : -1
01H : 0
|
16H : +22
DATA05 : SHARPNESS Gain
F0H : -16
|
FFH : -1
01H : 0
|
10H : +16
