E-65
Specifications
Model U2-1200/U2-817
Optical
Method of projection : DLP™ (single chip DMD)
DMD U2-1200: 0.7 inches 1024 ן768 dots
U2-817: 0.55 inches 800 ן600 dots
Lamp 200 W ultra-high pressure mercury lamp
Projection lens : Manual zoom ( ן1.2), manual focus, F = 2.4 to 2.6, f = 26.5 to 31.8 mm
Image size U2-1200: Minimum 27 inches (projection distance: 1.2 meters, tele mode)
Maximum 300 inches (projection distance: 11.5 meters, wide mode)
U2-817: Minimum 21 inches (projection distance: 1.2 meters, tele mode)
Maximum 300 inches (projection distance: 14.8 meters, wide mode)
Light Output U2-1200: 2000 ANSI lumens
U2-817:
1500 ANSI lumens
Contrast Ratio 1500:1 (Full on/off)
Electrical
Inputs Video (NTSC3.58/NTSC4.43/PAL/PAL-N/PAL-M/PAL60/SECAM)
RGB (Horizontal :15 to 85 kHz, Vertical 50 to 120 Hz)
Output VGA (640
ן480), S-VGA (800ן600), XGA (1024ן768) *
Color Reproduction Full color (16,770,000 colors)
Resolution U2-1200: VGA (640 ן480) expansion/true, S-VGA (800ן600) expansion/true
XGA (1024
ן768) true, S-XGA (1280ן1024) compression
U2-817: VGA (640 ן480) expansion/true, S-VGA (800ן600) true
XGA (1024 ן768) compression
Input Current 2.8 A
Power Requirement 100 - 240 V AC, 50/60 Hz
Power Consumption 280 watts
Mechanical
Dimensions Excluding Stand 230 mm (W) ן58 mm (H)ן295 mm (D)
9.0 in.(W) ן2.3 in.(H)ן11.6 in.(D)
Weight Approximately 2.5 kg / 5.5 lbs
Operational Temperatures Data projector: 5 ° to 35°C (41° to 95°F), 30 to 85% humidity
Regulations UL Approved (UL 1950, CSA 950)
Meets FCC Class A requirements
Meets EMC Directive (EN55022, EN55024)
Meets Low Voltage Directive (EN60950)
• Specifications and design are subject to change without notice.
* XGA can be supported for up to the horizontal synch range 68.7kHz and the vertical synch range 85Hz.
