E – 5
For video equipment connection
Audio video cable
(1 m/3.3 ft.) [1]
S-video cable
(1 m/3.3 ft.) [1]
Lens cap (attached to the lens of the unit) [1]
Carrying case [1]
How to use the carrying case
P r e p a r i n g t h e
r e m o t e c o n t r o l
Inserting the batteries
1 Press firmly and
slide the battery
cover off.
2 Insert the two
supplied batteries
(size AA/R6).
Ensure that the
polarities (+ and –)
of the batteries are
aligned correctly.
3 Slide the cover
back until it
snaps into place.
Notes
• If the remote control gets wet, wipe it dry immediately.
• Avoid excessive heat and humidity.
• If you will not be using the remote control for a long time, remove the
batteries.
• Do not mix new and old or different types of batteries.
• There are operations that can only be carried out by remote control.
Handle the remote control carefully.
Remote control effective range
The remote sensors are located on the front and back of the unit.
The controllable range is 50 degrees horizontally and 30 degrees
vertically relative to a line that is at a right angle to the remote
sensor. And the distance between the point of the remote control
and remote sensor must be shorter than four meters (13 feet).
Packing the unit
USER’S MANUAL
(this manual) [1]
About the lens cap
The lens cap is fixed on the bottom of the
unit as shown in the illustration below.
Packing the accesories
– + UP
ENT ER
DOW N
PO WER STA TUS
MEN U
SEL ECT
PC AUDIO RGB IN
MOUS E
AUDIO
S-VIDEO VIDEO L/MONO R
30˚
30˚
50˚
50˚
Quick Start Guide [1]
