E – 34
Optical
DMD TM Single Chip Digital Micro Device (DMD TM )
(U2-1130) (U2-1110)
1024
×
768 dots 1024
×
768 dots
Lens Manual zoom, manual focus
(U2-1130)
(U2-1110)
F=2.7 to 3.0 f=35 to 42 mm F=3.0 to 3.3 f=27.5 to 33 mm
(1.4 to 1.65 in.) (1.1 to 1.3 in.)
Lamp High Performance Compact Lamp 150 W
Image Size 635 to 7620 mm (25 to 300 in.) diagonal
Projection Distance 1.2 to 12.3m (3.9 to 40.4 ft.)
Light Output (U2-1130) (U2-1110)
1300 ANSI lumens (normally white) 1100 ANSI lumens (normally white)
Contrast Ratio 800 : 1
Electrical
Inputs Video (NTSC / PAL / SECAM / NTSC4.43)
RGB (H:15 to 85 kHz, V: 50 to 85 Hz)
Video Bandwidth 60 MHz
Color Reproduction Full color, 16.7 million colors simultaneously.
Horizontal Resolution NTSC 500, PAL 500, SECAM 300, NTSC4.43 350 TV lines
RGB 1024 dots horizontal, 768 dots vertical
Power Requirement 100 to 120/220 to 240 V AC, 50/60 Hz
Input Current 2.2A/1.0A (220W)
Mechanical
Dimensions 23.5 cm (W)
×
5.8 cm (H)
×
29.7 cm (D) / 9.3 in.(W)
×
2.3 in.(H)
×
11.7 in.(D)
Net Weight (U2-1130) (U2-1110)
2.6 kg / 5.7 lbs 2.5 kg / 5.5 lbs
Operational Temperatures Data projector: 5° to 35°C (41° to 95°F), 30 to 85% humidity
Remote control: 0° to 60°C (32° to 140°F)
Regulations UL Approved (UL 1950, CSA 950)
Meets DOC Canada requirements
Meets FCC Class A requirements
Meets EMC Directive (EN55022, EN61000-3-2, EN61000-3-3, EN50082-1)
Meets Low Voltage Directive (EN60950, TÜV GS Approved)
S p e c i f i c a t i o n s
