E – 10
• Projecting distance and image size
Diagonal image size (inch)
Projection distance
Using the ceiling mounting fixtures
When using the ceiling hanging fixtures, select “FRONT/CEILING” in “PROJECTION” of “SETTING MENU” (see pages 17 and 24).
Note
Installing the unit on the ceiling must be performed by qualified PLUS service personnel. Contact your PLUS dealer for more information. Never
attempt to install the unit yourself.
I n s t a l l a t i o n ( c o n t i n u e d )
Center of lens
Projection distance
Center of lens
151 to 154 mm/ 0.5 feet
In telephoto mode
4,712 to 4,742 mm/
15.5 to 15.6 feet
In wide mode
5,613 to 5,660 mm/
18.4 to 18.6 feet
12.7˚ – 12.1˚
15.1˚ – 14.5˚
12.3m / 40.4 feet
9.8m / 32.2 feet
4.9m / 16.1 feet
3.9m / 12.8 feet
2.9m / 9.5 feet
1.9m / 6.2 feet
0 1 2 3 4 5 6 7 8 9 10 11 12 (m)
0 3.3 6.6 9.8 13.1 16.4 19.7 23.0 26.2 29.5 32.8 36.1 39.4 (feet)
Tele. – Wide
250 ″ – 300 ″
200 ″ – 240 ″
100
″
– 120
″
80
″
– 96
″
60
″
– 72
″
40
″
– 48
″
25 ″ – 30 ″
Height of the
projecting image
6m / 19.7 feet
5m / 16.4 feet
4m / 13.1 feet
3m / 9.8feet
2m / 6.6 feet
1m / 3.3 feet
0m / 0 feet
Image center in
wide mode
Image center
in telephoto
mode
1.2m
3.9 feet
Height of the
projecting image
1m / 3.3 feet
2m / 6.6 feet
3m / 9.8feet
4m / 13.1 feet
5m / 16.4 feet
6m / 19.7 feet
0 1 2 3 4 5 6 7 8 9 10 11 12 (m)
0 3.3 6.6 9.8 13.1 16.4 19.7 23.0 26.2 29.5 32.8 36.1 39.4 (feet)
12.3m / 40.4 feet
9.8m / 32.2 feet
4.9m / 16.1 feet
3.9m / 12.8 feet
2.9m / 9.5 feet
1.9m / 6.2 feet
(25 to 30 ″ )
1.2m / 3.9 feet
(100 to 120 ″ )
(250 to 300 ″ )
(200 to 240 ″ )
(60 to 72
″
)
(80 to 96 ″ )
(40 to 48 ″ )
