Page 31: Figure 3-1, Channel dvr front panel
Configuration
Document 800-00918
Rev E
31
12/07
3
Configuration
Note
Your DVR should be completely installed before proceeding. If
you have not installed the DVR, please see
Chapter 2,
Installation
.
Front Panel Controls
The front panel looks and operates much like a VCR combined with a multiplexer. Many
of the buttons have multiple functions. The following describes each button and control.
Take a few minutes to review the descriptions. You will use these to initially set up your
DVR and for daily operations.
Note
You can also use a USB mouse (not supplied) to navigate
through the screens and menus much like you would on a
computer.
Figure 3-1
16-Channel DVR Front Panel
1
9
10
11
12
13
14
15
16
2
3
4
5
6
7
8
8
9
10 11 12 13
7
4
5
1
3
2
6
14 15
16
17
