Operation
114
Loading a Preset
Figure 4-8
Preset View Screen
1.
Press
to load the PTZ preset.
The Preset View dialog box appears.
2.
Select the desired preset and then press
to load the preset.
Using a Mouse for Convenient PTZ Control
Position the mouse pointer at the bottom of the screen, and the following PTZ toolbar
displays.
Figure 4-9
PTZ Toolbar
Table 4-5
PTZ Toolbar Tools
Icons
Action
Zoom In / Out
Focus Near / Far
Iris Open / Close
Set / Load Preset
Arrows
Pan or tilt
