Fan Power, Switched (CN15)
The switched fan power connector (CN15) is an optional fan connector which allows the system to power the
fan only when the processor temperature reaches high temperatures.
To utilize this connector, refer to the
Thermal Management section on page 72.
Table 38
Fan Power, Switched (CN15)
Pin
Signal
Function
1
CPU_FAN_PWM
+5 Volts DC, switched
2
GND
Ground
