37
Installing memory
You can add memory to your computer to increase system performance. Your
computer has two DIMM connectors for installing memory. The maximum
amount of SDRAM memory is 512 MB.
To install a DIMM, do the following:
1. Remove the computer cover. See “Removing the computer cover” on page 36.
2. Locate the DIMM sockets on the system board. See “System board” on page
35.
3. Open the module retaining clips on one of the DIMM sockets.
Note: If you are replacing an existing DIMM, remove the existing DIMM.
4. Position the new DIMM over the socket, making sure that the notches in the
DIMM are aligned with the tabs on the socket. Push the DIMM straight down
into the connector until the retaining clips close.
5. Replace the computer cover.
Notches
