1.5 Front view of 8KE4/8KE8
8KE4:
8430/8830/8KE4/8KE8 User’s manual, Jan 2005, Version 1.0, 8MS-002-10 ----- 16
+VS
GND
INIT*
INIT*COM
Input:
10~30VDC
Initialize
Ethernet
10 BaseT
8KE8:
+ V S
In p u t:
1 0 ~ 3 0 V D C
G N D
IN IT *
IN IT *C O M
In itia lize
E th e rn e t
1 0 B a se T
Power: 10~30V
DC
Initial pin
RS-232
(COM1)
Slot 0 Slot 1
10M Ethernet port
Power: 10~30V
DC
Small Man Machine Interface
Small Man Machine Interface
Initial pin
RS-232
(COM1)
Slot 2 Slot 3
10M Ethernet port
Slot 0 Slot 2 Slot 4
Slot 3
Slot 6
Slot 5 Slot 7 Slot 1
