18
COMPUTER INSTRUCTIONS (cont.)
PARTS LIST ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
QTY.
4
1
1
18
4
2
2
1
1
1
1
1
1
24
2
6
6
1
1
2
1
1
1
8
1
2
8
8
1
2
6
2
2
1
1
1
2
PART NAME
M8 x 1.25 x 60mm Carriage Bolt
Front Foot Tube
Frame
M8 ID x 18.8mm OD Flat Washer
M8 x 1.25 Cap Nut
Foot Cap
End Cap
Rear Foot Tube
Support Tube
Right Rear Cover
Left Rear Cover
Right Front Cover
Left Front Cover
M4 x 12mm Sheet Metal Screw
M4 x 16mm Sheet Metal Screw
M5 x 115mm Machine Screw
M5 Hex Nut
Seat Carriage Plug
Seat Carriage
Seat Carriage Bushing
Grip
Square Plug
Carriage Tube
M8 x 15mm Button Head Screw
Seat Cushion
Back Cushion
M6 x 1 x 12mm Phillips Head Screw
M6 Washer
Handlebar
M8 x 45mm Button Head Screw
M8 Locknut
Sleeve
Handlebar Plug
Right Pedal
Left Pedal
Crank
Pedal Strap
ITEM
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
QTY .
1
1
1
1
2
8
1
1
1
1
2
2
1
6
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
2
2
1
3
2
1
1
P ART NAME
Reed Switch
Console Tube
Console
Front Handlebar
M8 x 60mm Machine Screw
M6 x 1 x 10mm Machine Csrew
Book Holder
Center Cover
Spring
"V" Belt
M10 Washer
M10 Cap Nut
Pulley
M6 x 1 Nut
Magnet
Mag Brake
Belt Tension Bracket
M6 x 1 x 20mm Machine Screw
M8 x 45mm Button Head Screw
Idler Bushing
Idler Pulley
Bearing Cup
Bearing
Slotted Bearing Nut
Notched Bearing Nut
Crank Washer
Crank Nut
Gear Box
Gear Box Plate
Eyebolt
Adjustment Channel
M6 x 1 Locknut
M3.5 x 15mm Sheet Metal Screw
M4 x 16mm Sheet Metal Screw
Crank Washer
Owner's Manual
1. Press START/PAUSE for 2 seconds to
clear monitor.
2. Press to select desired program.
Press ENTER.
3. Press to set desired time.
4. Enter AGE if program 11 or 12 was selected.
5. Press START and begin riding.
6. Press MODE while riding to select a function.
DIRECTIONS
BPM
Customer
Service:
800 - 321 - 9236
Heart Rate Training Zones
165
Age 20 30 40 50 60 70 80
Max Fat Burn
Fat Burn
Aerobic
118
105 110 115
95 103
90
145
125
120 130
115 125
110 125
130
140
138 145
155
