Source and Output refer to the way you use devices with MX-4 DV.

Source — A source is an input device. Each source provides a video signal, audio signal, or both.
You use the MX-4 DV to combine and (optionally) animate these signals.

Output — An output is a device on which you record and/or broadcast a signal. The signal might
contain video, audio, or both. This signal is often a mix of signals coming into MX-4 DV from one
or more sources. The output device might be a VCR with an optional monitor attached, or it might
be a live broadcast.

REVIEW

AND

ROGRAM

ONITORS

The MX-4 DV designates monitors as either Preview or Program to indicate how a particular mon-
itor may be used. This manual uses the following picture to distinguish between the two monitors.

MX-4 DV

Source

Output
