Power button board
Description Spare part number
Power button board (includes cable) 701686-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement.
Before removing the power button board, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 32 ).
5. Remove the keyboard (see Keyboard on page 36 ).
6. Remove the top cover (see Top cover on page 40 ).
Remove the power button board:
1. Turn the top cover upside down, with the front toward you.
2. Remove the Phillips screw (1) and tape that secure the power button board to the top cover.
3. Release the clips, lift the power button board (2), and carefully slide the power button cable out
from the guides (3) to remove the power button board.
Reverse this procedure to install the power button board.
Component replacement procedures 43
