Reference materials, A. appliance dimension diagram – Hearth and Home Technologies Direct Vent Gas Appliance CD4842LR User Manual
Page 61
Heatilator • Caliber CD Series • 4040-263 Rev N • 11/08
61
16
16
Reference Materials
C
A
23 in.
(584 mm)
15-1/4 in.
(387 mm)
38-1/2 in.
(978 mm)
33-1/2 in.
(851 mm)
1-1/2 in.
(38 mm) 2-3/8 in.
(60 mm)
14-1/8 in.
(365 mm)
5-7/8 in.
(149 mm)
2 in.
(51 mm)
Alternative
Gas Line
Access
Electrical
Access
38-1/4 in.
(972 mm)
B
3 in.
(76 mm)
27-1/4 in.
(692 mm)
6-1/2 in.
(165 mm)
Gas Line
Access
A. Appliance Dimension Diagram
Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3.
Figure 16.1 Appliance Dimensions
Model #
A
B
C
CD4236
in.
41
36
24 1/4
mm
1041
914
616
CD4842
in.
47
42
30 1/4
mm
1194
1067
768
