Heatilator • Caliber CD Series • 4040-263 Rev N • 11/08 29
3. Rear Vent - Horizontal Termination
Figure 7.10
Figure 7.11
No Elbow
One 45° Elbow
18 in. (457 mm) max.
18 in. (457 mm) max.
