HP dx5150 - Manual (Page 10)

Hood Sense Header No No
Multibay Header No No
Multport Header No No
NIC supported features:
WOL (Wake-On-Lan®)
Yes Yes
AOL (Alert-On-LAN®) No No
SOS - Network based alerting Yes Yes
ASF 1.0 (Alert Standards Format) Yes Yes
PXE (Pre-Boot Execution Environment) Yes Yes
Power Supply Header Yes Yes
Power Switch, Power LED
& Hard Drive LED Header Yes Yes
Password Clear Header Yes Yes
Riser Connector No No
SCSI LED Header Yes Yes
ACPI-Ready Hardware
Advanced Configuration and Power
Management Interface (ACPI).
It allows the system to wake from a
low power mode.
It controls system power
consumption, making it possible to
place individual cards and
peripherals in a low-power or
powered-off state without affecting
other elements of the system.
Yes Yes
Dual-State Power Button
Power button acts as both an on/off
button and suspend-to-sleep button.
Yes Yes
Chassis Chassis Chassis Chassis
Color
Carbonite/Silver Carbonite/Silver
System Board Form Factors Supported Standard uATX Standard uATX
Cooling Solutions Supported Yes Yes
Power Supply Fan (Variable Speed) Yes Yes
Processor Fan-Heatsink
(Variable Speed) Yes Yes
System Fan (Variable Speed) Standard Front Headphone, Microphone,
and (2) USB 2.0 Standard Front Headphone, Microphone,
and (2) USB 2.0
Front I/O Standard ATX I/O Connectors (6 USB 2.0,
1 VGA, 1 DVI-D, 1 Audio Out, 1 Audio In,
1 Microphone, 1 Serial, 1 Parallel, 2 PS2,
1 RJ-45) Standard ATX I/O Connectors (6 USB 2.0,
1 VGA, 1 DVI-D, 1 Audio Out, 1 Audio In,
1 Microphone, 1 Serial, 1 Parallel, 2 PS2,
1 RJ-45)
Rear I/O Yes Yes
Internal Speaker Kensington Cable Lock (optional) Kensington Cable Lock (optional)
Security Locks Supported Hood Cover Security Loop (standard but
Lock not included) Hood Cover Security Loop (standard but
Lock not included)
QuickSpecs
HP dx5150 Business PC HP dx5150 Business PC HP dx5150 Business PC HP dx5150 Business PC
Standard Features – Base Unit Details
DA - 12105 Worldwide — Version 7 — August 23, 2005 Page 10
