Heat & Glo • 6000GCF-IPI, 6000GCF-IPILP • 2110-900 Rev. G • 9/08 16
Figure 5.8
2. Top Vent - Vertical Termination - (continued)
Three Elbows
INSTALLED
HORIZONTALLY
V
2
H
2
H
1
V
1
V
1
H
1
+ H
2
V
2
V
1
+ V
2
Minimum H
1
+ H
2
Maximum
6 in. 152 mm 3 ft 914 mm * * * 3 ft 914 mm
1 ft 305 mm 3 ft 914 mm * * * 3 ft 914 mm
2 ft 610 mm 6 ft 1.8 m * * * 6 ft 1.8 m
4 ft 1.2 m 12 ft 3.7 m * * * 12 ft 3.7 m
H
1
+ H
2
= 17 ft (5.2 m) Maximum
V
1
+ V
2
+ H
1
+ H
2
= 50 ft (15.2 m) Maximum
V
1
= 6 inches (152 mm) Minimum
