Honeywell FUSION User Manual
Page 101
SEARCH OPTIONS
6–17
6.15 STATUS SEARCH, CONTINUED
1
2
3
1 Camera
Displays the cameras in linear format.
Scroll down using the scroll bar on the right.
2 Hours
The hours 0-23 (24 hours) are listed.
3 Recording
Block Displays in blue where video is recorded.
Areas of no recording are displayed in white.
6.15.1 PERFORMING A STATUS SEARCH
1.
Select
the
Status Search button to open the Status Search window.
2. Use the mouse to click on an area of the blue recording block.
Only one camera can be displayed at a time.
6.16 AUDIO
Audio is played back at 48,000Hz.
To play audio with the video:
1. Select a single camera by turning off all cameras but one using the
Camera Select buttons. The audio buttons will be displayed.
2. Select a single audio channel to play. When an audio channel is selected, the
Time Synch button will automatically be selected.
3.
Press
the
Play button.
