25
WideSide® View
(with optional-purchase WideSide® transducer)
WideSide® View is only available if you have purchased and connected an optional-purchase
WideSide® transducer accessory and when Transducer Select is set to WideSide® (see Sonar Menu
Tab: Transducer Select). The WideSide® View displays information from the 455 kHz WideSide®
transducer. Three views are available: Left, Right and Both. The default view is Both. Information
from both the left and right beams are displayed simultaneously. The depth of the water beneath
the boat is always displayed. A bottom contour may be present while bank fishing or fishing river
channels. When fishing in the open water, a bottom contour will not be present, and only sonar
returns from either debris or fish will be displayed.
WideSide View
Left Side View
Bank Contour
Water Surface
Line
Depth
Right Side View
Open Water
(no bottom
contour visible
on-screen)
Side Beam
Depth Range
