28
J. Startup
CAUTION
1. All parts are factory-adjusted. Improper adjustments may result in failure.
2. On remote air-cooled model, the icemaker should have power for a minimum
of 4 hours prior to startup to prevent compressor damage.
3. If the icemaker is turned off, wait for at least 3 minutes before restarting the
icemaker to prevent damage to the compressor.
4. Do not operate the icemaker in the "WASH" position without water in the
water tank. This will cause damage to the water pump seal.
5. At startup, confirm that all internal and external connections are free of leaks.
1) Open the water supply line shut-off valve.
2) Remove the front panel.
3) Move the control switch on the control box to the "ICE" position.
4) Replace the front panel in its correct position.
5) Turn on the power supply, and allow the icemaker to operate for a total of 10 minutes.
6) Turn off the power supply, then remove the front panel.
7) Remove the insulation panel. Remove the cap located on the front bottom part of the
ice dropping hole. Drain the water tank. See Fig. 17.
8) Replace the cap, insulation panel, and front panel in their correct positions. Be careful
not to cross thread the cap.
9) Clean the storage bin liner using a neutral cleaner. Rinse thoroughly after cleaning.
10) Turn on the power supply to start the automatic icemaking process.
11) When the icemaker is running, hold an ice cube in contact with the bulb. The icemaker
should stop within 3 to 10 seconds. Adjustment may be needed, particularly at higher
altitude locations.
Fig. 17
Inside of Ice
Dropping Hole
Front
Cube Guide
Separator
Float Switch
Assembly
Cap
