Fig. 14 – Hoshizaki KM-1301SWH/3 User Manual
Page 25
25
KM-1301SAH/3
KM-1301SRH/3
Bin Drain Outlet 3/4" FPT
Icemaker Water Supply Line Shut-Off Valve
Icemaker Water Supply Line Drain Valve
Icemaker Water Supply Inlet 1/2" FPT
Icemaker
Drain Outlet
3/4" FPT
Condensation
Drain Outlet
3/8" OD
Stainless Tube
Bin
Icemaker
Remote Condenser Line Set Connections
Separate piping to approved drain.
Leave a 2 inch (5 cm) vertical air gap
between the end of each pipe and the
drain.
2 inch (5 cm)
air gap
Floor
Drain
Fig. 14
