4
[d] KM-260BWH
AC SUPPLY VOLTAGE 115/60/1
AMPERAGE 7.5 A ( 5 Min. Freeze AT 104°F / WT 80°F)
MAXIMUM FUSE SIZE N/A
APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (°F)
PER 24 HR. Temp.(°F) 50 70 90
lbs./day ( kg/day ) 70 *268 (122) 259 (117) 242 (110)
Reference without *marks 80 261 (118) 247 (112) 228 (103)
90 259 (117) *237 (108) 218 (99)
100 254 (115) 233 (106) *201 (91)
SHAPE OF ICE Crescent Cube
ICE PRODUCTION PER CYCLE 5.0.lbs. (2.26kg) 238 pcs.
APPROXIMATE STORAGE CAPACITY 100 lbs(45Kg).
ELECTRIC & WATER CONSUMPTION 90/70°F 70/50°F
ELECTRIC W (kWH/100 lbs.) 630(6.37) 620(5.59)
WATER gal./24HR (gal./100 lbs.) 62(26.3) 77(28.7)
COND.WATER gal./24HR (gal./100 lbs) 285(120.6) 151(56.2)
CEC/CEE TIER LEVEL 3
EXTERIOR DIMENSIONS (WxDxH) 30" x 28" x 39" (762 x 712 x 990 mm)
Including 6" legs
EXTERIOR FINISH Stainless Steel, Galvanized Steel (Rear)
WEIGHT Net 154 lbs. (70 kg), Shipping 187 lbs. (85 kg)
CONNECTIONS - ELECTRIC Cord Connection
- WATER SUPPLY Inlet 1/2" FPT
- DRAIN Outlet 3/4" FPT
CONDENSER WATER Inlet 1/2" FPT
Outlet 1/2" FPT
CUBE CONTROL SYSTEM Float Switch
HARVESTING CONTROL SYSTEM Hot Gas and Water, Thermistor and Timer
ICE MAKING WATER CONTROL Timer Controlled. Overflow Pipe
COOLING WATER CONTROL N/A
BIN CONTROL SYSTEM Mechanical Level Switch with Delay
COMPRESSOR Hermetic, Model SC10CL
CONDENSER Water-Cooled, Tube type
EVAPORATOR Vertical type, Stainless Steel and Copper
REFRIGERANT CONTROL Thermostatic Expansion Valve
REFRIGERANT CHARGE R-404A 12.7oz (360g)
DESIGN PRESSURE High 467PSIG, Low 230PSIG
P.C. BOARD CIRCUIT PROTECTION High Voltage Cut-out ( Internal )
COMPRESSOR PROTECTION Auto-reset Overload Protector ( Internal )
REFRIGERANT CIRCUIT PROTECTION Auto-reset High Pressure Control Switch
LOW WATER PROTECTION Float Switch
ACCESSORIES -SUPPLIED Ice Scoop, 6" leg 4 pcs
OPERATING CONDITIONS VOLTAGE RANGE 104 - 127 V
AMBIENT TEMP. 45 -100° F
WATER SUPPLY TEMP. 45 - 90° F
WATER SUPPLY PRESSURE 10 - 113 PSIG
DRAWING NO. (DIMENSION) 373569S01
We reserve the right to make changes in specifications and design without prior notice.
