Hoshizaki KM-260BAH User Manual
Page 32
27
[b] KM-201BWH, KM-260BWH
Evaporator
Float
Switch
Drain
Cube Guide
Drier
Cleaning
V
alv
e
Thermistor
Suction
Line
Water
Supply
Water Valve
Spray Tube
Water Condenser
Expansion Valve
Compressor
Access Valve
Strainer
Hot Gas
Valve
High Pressure
Switch
Refrigerant Circuit
Water Circuit
Discharge Line
Insulation Tube
Pump
Motor
Water Tank
Drain
Drain
Valve
Water
Supply
Water Regulator
