Hoshizaki KM-260BAH User Manual
Page 12
7
[c] KM-260BWH
Top Panel
Front Cover
Side
Panel
(L)
Rear
Panel
Door
Side
Panel
(R)
Louver
Power
Supply
Cord
Leg
Top
Cover
Drain
Valve
Hot
Gas
Valve
Thermistor
Cleaning
Valve
Water
Regulator
Evaporator
Condenser
Separator
Water
Tank
Compressor
Expansion
Valve
Water
Valve
Overfl ow Pipe
Drier
Control Switch
Float Switch
Service Switch
Control
Box
Front View
Rear View
Bin
Control
Switch
With Tank Removed
