MODEL NUMBER 128602-1102-E1 BRIGGS & STRATTON 4-CYCLE ENGINE
KEY PART
NO. NO.
DESCRIPTION
445 697029 Filter,
Air Cleaner Cartridge
455 791960 Cup-Flywheel
456 692299 Plate-Pawl Friction
459 281505s Pawl-Ratchet
505 691251 Nut
(Governor Control Lever)
523 499621 Dipstick
524 692296 • Seal-Dipstick Tube
525 495265 Tube-Dipstick
562 92613 Bolt
(Governor Control Lever)
584 697734 Cover-Breather Passage
585 691879 • Gasket-Breather Passage
592 690800 Nut (Rewind Starter)
597 691696 Screw
(Pawl Friction Plate)
601 791850 Clamp-Hose
608 497680 Starter-Rewind
613 691108 Screw (Muffl er)
613A 691140 Screw (Muffl er)
615 690340 Retainer-Governor Shaft
616 698801 Crank-Governor
619 691108 Screw
(Cylinder Head Plate)
621 692310 Switch-Stop
633 691321 ؇ Seal-Throttle Shaft
635 66538s Boot-Spark Plug
670 692294 Spacer-Fuel Tank
684 690345 Screw
(Breather Passage Cover)
689 691855 Spring-Friction
718 690959 Pin-Locating
741 794388 Gear-Timing
745 691648 Screw (Brake)
830 694544 Stud (Rocker Arm)
842 691031 • Seal-O Ring
(Dipstick Tube)
847 692047 Assembly-Dipstick/Tube
851 493880s Terminal-Spark Plug
868 795440 •+ Seal-Valve
883 691893 •+ Gasket-Exhaust
886 696268 Gasket Kit,
Cylinder Head/Plate
914 691108 Screw (Rocker Cover)
914A 691127 Screw (Rocker Cover)
921 691465 Cover-Blower Housing
922 692135 Spring-Brake
923 695891 Brake
KEY PART
NO. NO.
DESCRIPTION
957 793606 Cap-Fuel Tank
966 690243 Base-Air Cleaner Primer
967 273356s Filter-Pre Cleaner
968 691342 Cover-Air Cleaner
969 691138 Screw
(Blower Housing Cover)
972 699374 Tank-Fuel
975 493640 Bowl-Float
976 694395 Primer-Carburetor
977 792385 Set-Carburetor Gasket
993 694088 •+ Gasket,
Cylinder Head Plate
1022 691890 •+ Gasket-Rocker Cover
1023 499624 Cover-Rocker Arm
1026 795444 Rod-Push
1029 691230 Arm-Rocker
1034 691343 Guide-Push Rod
1036 - - - Label-Emissions
(Available from an
authorized Briggs
& Stratton Service Dealer)
1058 277102TRI Operator’s Manual
1059 692311 Kit-Screw/Washer
1095 792386 Set-Valve Gasket
1210 498144 Assembly-Pulley/Spring
(Pulley)
1211 498144 Assembly-Pulley/Spring
(Spring)
1329 12S502-0025 Replacement Engine
(Replacement engine
listed is not available in
the State of California.
Repair with individual
parts.)
1330 272147 Repair Manual
- - 398067 Spark Arrester
(available accessory)
• Included in Engine Gasket Set, Key No. 358
Ø Included in Carb. Overhaul Kit, Key No. 121
‡ Included in Carb. Gasket Set, Key No. 977
+ Included in Valve Gasket Set, Key No. 1095
NOTE: All component dimensions given in U.S.
inches. 1 inch = 25.4 mm
3
DO:
• Mow across the face of slopes: nev er
up and down. Exercise extreme caution
when changing direction on slopes.
• Remove obstacles such as rocks, tree
limbs, etc.
• Watch for holes, ruts, or bumps. Tall
grass can hide obstacles.
DO NOT:
• Do not trim near drop-offs, ditches or
embankments. The operator could lose
footing or balance.
• Do not trim excessively steep slopes.
• Do not mow on wet grass. Reduced
footing could cause slipping.
III. CHILDREN
Tragic accidents can occur if the op er a tor is
not alert to the presence of children. Children
are often attracted to the ma chine and the
mowing activity.
Never assume that children
will remain where you last saw them.
• Keep children out of the trimming area
and under the watchful care of an oth er
re spon si ble adult.
• Be alert and turn machine off if chil dren
enter the area.
• Before and while walking back wards,
look behind and down for small chil dren.
• Never allow children to operate machine.
• Use extra care when approaching blind
corners, shrubs, trees, or other objects
that may obscure vision.
IV. SAFE HANDLING OF GASOLINE
Use extreme care in handling gasoline.
Gasoline is extremely fl ammable and the
vapors are explosive.
• Extinguish all cigarettes, cigars, pipes
and other sources of ignition.
• Use only an approved container.
• Never remove gas cap or add fuel with
the engine running. Allow engine to
cool before refueling.
• Never refuel the machine indoors.
• Never store the machine or fuel contain-
er where there is an open fl ame, spark
or pilot light such as a water heater or
on other appliances.
• Never fi ll containers inside a vehicle, on
a truck or trailer bed with a plastic liner.
Always place containers on the ground
away from your vehicle before fi lling.
• Remove gas-powered equipment from the
truck or trailer and refuel it on the ground. If
this is not possible, then refuel such equip-
ment with a portable container, rather than
from a gasoline dispenser nozzle.
• Keep the nozzle in contact with the rim
of the fuel tank or container opening at
all times until fueling is complete. Do
not use a nozzle lock-open device.
• If fuel is spilled on clothing, change
clothing immediately.
• Never overfi ll fuel tank. Replace gas
cap and tighten securely.
V. GENERAL SERVICE
• Never run machine inside a closed area.
• Never make adjustments or repairs with
the engine (motor) running. Dis con nect the
spark plug wire, and keep the wire away
from the plug to prevent ac ci den tal starting.
• Keep nuts and bolts, especially blade
attachment bolts, tight and keep equip-
ment in good condition.
• Never tamper with safety devices.
Check their proper operation reg u lar ly.
• Keep machine free of grass, leaves, or
other debris build-up. Clean oil or fuel spill-
age. Allow machine to cool before storing.
• Stop and inspect the equipment if you
strike an object. Repair, if nec es sary,
before restarting.
• Never attempt to make wheel height
adjustments while the engine is running.
• Grass catcher components are sub ject to
wear, dam age, and de te ri o ra tion, which
could expose moving parts or allow objects
to be thrown. Frequently check com po -
nents and replace with man
u fac tur er’s
recommended parts, when necessary.
• Mower blades are sharp and can cut.
Wrap the blade(s) or wear gloves, and
use extra caution when ser vic ing them.
• Do not change the engine governor set-
ting or overspeed the engine.
• Maintain or replace safety and instruc-
tion labels, as necessary.
WARNING: This lawn mower is equipped with an internal com bus tion engine and
should not be used on or near any un im proved forest-covered, brush-covered or
grass-cov ered land unless the engine’s exhaust system is equipped with a spark
arrester meeting applicable local or state laws (if any). If a spark arrester is used, it
should be maintained in effective working order by the operator.
In the state of California the above is required by law (Section 4442 of the California Public
Resources Code). Other states may have similar laws. Federal laws apply on federal
lands. A spark arrester for the muffl er is available through your nearest Husqvarna or
other authorized service center (See the REPAIR PARTS section of this manual).
