4
WARRANTY
SECTION 1: LIMITED WARRANTY
Husqvarna Forest & Garden Company (“Husqvarna”)
warrants Husqvarna product to the original purchaser
to be free from defects in material and workmanship
from the date of purchase for the “Warranty Period” of
the product as set forth below:
2 YEAR NON-COMMERCIAL WARRANTY: Auto-
matic Mower, Riding lawn mowers, yard and garden
tractors, walk behind mowers, tillers, chain saws,
trimmers, brushcutters, clearing saws, snow blowers,
handheld blowers, backpack blowers, hedge trimmers,
electrical products and power-assist collection systems
for non com mer cial, nonprofessional, noninstitutional or
nonincome producing use, except as herein stated.
Emission control system components necessary to
comply with CARB-TIER-II and EPA regulations.
Husqvarna Safety Apparel carries a 90-day warranty
from the date of the customer’s original purchase for
defects in material and workmanship. Normal wear,
tear or abuse is not covered under warranty. Product
must be returned to Charlotte with a warranty claim
form. All care and maintenance instructions must be
followed as stated by the manufacturer on the care
label. The fi t of the protective apparel/boot is not
covered under warranty.
SECTION 2: HUSQVARNA’S OBLIGATIONS UNDER
THE WARRANTY
Husqvarna will repair or replace defective components
without charge for parts or labor if a component fails
because of a defect in material or workmanship during
the warranty period.
SECTION 3: ITEMS NOT COVERED BY THIS WAR-
RANTY
The following items are not covered by this warranty:
(1)Normal customer maintenance items which become
worn through normal regular use, including, but
not limited to, belts, blades, blade adapters, bulbs,
fi lters, guide bars, lubricants, rewind springs, saw
chain, spark plugs, starter ropes and tines;
(2) Natural discoloration of material due to ultraviolet
light;
(3) Lawn and garden attachments are covered by a
third party which gives a warranty, all claims for
warranty should be sent to the manufacturer; and
(4)Emission Control System components necessary
to which are manufactured by third party engine
manufacturer.
SECTION 4: EXCEPTIONS AND LIMITATIONS
This warranty shall be inapplicable to defects resulting
from the following:
(1) Accident, abuse, misuse, negligence and neglect,
including stale fuel, dirt, abrasives, moisture, rust,
corrosion, or any adverse reaction due to incorrect
storage or use habits;
(2) Failure to operate or maintain the unit in accor-
dance with the Owner’s/Operator’s manual or
instruction sheet furnished by Husqvarna;
(3) Alterations or modifi cations that change the
intended use of the product or affects the product’s
performance, operation, safety, or durability, or
causes the product to fail to comply with any ap-
plicable laws; or:
(4) Additional damage to parts or components due to
continued use occurring after any of the above.
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF
THE PUR CHAS ER. HUSQVARNA SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUEN-
TIAL DAMAGES FOR BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY ON THESE PRODUCTS
EXCEPT TO THE EXTENT PROHIBITED BY AP-
PLICABLE LAW. ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICU-
LAR PURPOSE ON THESE PRODUCTS IS LIMITED
IN DURATION TO THE WARRANTY PERIOD AS
DEFINED IN THE LIMITED WARRANTY STATE-
MENT. HUSQVARNA RE SERVES THE RIGHT TO
CHANGE OR IMPROVE THE DESIGN OF THE
PRODUCT WITHOUT NO TICE, AND DOES NOT
ASSUME OBLIGATION TO UPDATE PREVIOUSLY
MANUFACTURED PROD UCTS.
Some states do not allow the exclusion of incidental
or consequential damages, or limitations on how long
an implied warranty lasts, so the above limitations or
exclusions may not apply to you. This warranty gives
you specifi c legal rights, and you may also have other
rights which vary from state to state.
SECTION 5: CUSTOMER RESPONSIBILITIES
The product must exhibit reasonable care, mainte-
nance, operation, storage and general upkeep as
written in the maintenance section of the Owner’s/
Operator’s manual. Should an operational problem
or failure occur, the product should not be used, but
delivered as is to an authorized Husqvarna dealer for
evaluation. Proof of purchase, as explained in section
6, rests solely with the customer.
SECTION 6: PROCEDURE TO OBTAIN WARRANTY
CONSIDERATION
It is the Owner’s and Dealer’s responsibility to make
certain that the Warranty Registration Card is properly
fi lled out and mailed to Husqvarna Forest & Garden
Company. This card should be mailed within ten (10)
days from the date of purchase in order to confi rm the
warranty and to facilitate post-sale service.
Proof of purchase must be presented to the authorized
Husqvarna dealer in order to obtain warranty service.
This proof must include date purchased, model num-
ber, serial number, and complete name and address of
the selling dealer.
To obtain the benefi t of this warranty, the product
believed to be defective must be delivered to an
authorized Husqvarna dealer in a timely manner, no
later than thirty (30) days from date of the operational
problem or failure. The product must be delivered at
the owner’s expense. Pick-up and delivery charges are
not covered by this warranty. An authorized Husqvarna
dealer can be normally located through the “Yellow
Pages” of the local telephone directory or by calling
1-800-HUSKY62 for a dealer in your area.
HUSQVARNA
7349 Statesville Road
Charlotte, NC 28269
531 83 81-23 2002
45
MODEL NUMBER 128602-1102-E1 BRIGGS & STRATTON 4-CYCLE ENGINE
KEY PART
NO. NO.
DESCRIPTION
1 692670 Cylinder Assembly
2 399269 Kit-Bushing/Seal
3 299819s • Seal-Oil (Magneto Side)
4 493279 Sump-Engine
5 792381 Head-Cylinder
7 697230 •+ Gasket-Cylinder Head
8 495786 Breather Assembly
9 699833 • Gasket-Breather
10 691125 Screw
(Breather Assembly)
11 691781 Tube-Breather
11A 692937 Tube-Breather
12 692232 • Gasket-Crankcase
13 691137 Screw (Cylinder Head)
15 691680 Plug-Oil Drain
16 691456 Crankshaft
20 399781s • Seal-Oil (PTO Side)
22 691092 Screw (Engine Sump)
23 697610 Flywheel
24 222698s Key-Flywheel
25 795429 Piston Assembly
(Standard Size)
795430 Piston Assembly
(.020" Oversize)
26 795431 Ring Set (Standard)
795432 Ring Set (.020" Oversize)
27 691866 Lock-Piston Pin
28 499423 Pin-Piston
29 499424 Rod-Connecting
32 691664 Screw (Connecting Rod)
32A 695759 Screw (Connecting Rod)
33 499642 Valve-Exhaust
34 499641 Valve-Intake
35 691304 Spring-Valve (Intake)
36 691304 Spring-Valve (Exhaust)
37 793756 Guard-Flywheel
40 692194 Retainer-Valve
43 691997 Slinger-Governor/Oil
45 690977 Tappet-Valve
46 694039 Camshaft
48 692748 Short Block
51 692668 • ؇+ Gasket-Intake
51A 692555 •Ø‡+ Gasket-Intake
51B 697735 •Ø‡+ Gasket-Intake
55 691421 Housing-Rewind Starter
58 697316 Rope-Starter
(Cut to Required Length)
60 281434s Grip-Starter Rope
KEY PART
NO. NO.
DESCRIPTION
65 690837 Screw (Rewind Starter)
78 691108 Screw (Flywheel Guard)
95 691636 Screw (Throttle Valve)
97 790121 Shaft-Throttle
104 691242 Ø Pin-Float Hinge
117 498981 Jet-Main (Standard)
118 498978 Jet-Main (High Altitude)
121 792383 Kit-Carburetor Overhaul
122 792382 Spacer-Carburetor
125 790120 Carburetor
127 694468 Ø Plug-Welch
130 696564 Valve-Throttle
133 398187 Float-Carburetor
134 398188 Ø Valve-Needle/Seat
137 693981 ؇ Gasket-Float Bowl
163 691894 •Ø‡+ Gasket-Air Cleaner
187 791766 Line-Fuel
(Cut to Required Length)
188 691147 Screw (Control Bracket)
190 690940 Screw (Fuel Tank)
192 694543 Ball-Rocker Arm
202 691303 Link-Mechanical Governor
209 691851 Spring-Governor
222 697614 Bracket-Control
227 691467 Control Lever-Governor
238 691300 Cap-Valve
259 691189 Bracket-Casing Clamp
276 271716 ؇ Washer-Sealing
287 690940 Screw (Dipstick Tube)
300 697590 Muffl er
304 695976 Housing-Blower
305 691108 Screw (Blower Housing)
306 691232 Shield-Cylinder
307 690345 Screw (Cylinder Shield)
332 690662 Nut (Flywheel)
333 802574 Armature-Magneto
334 691061 Screw
(Armature Magneto)
337 692051 Plug-Spark
356 692390 Wire-Stop
358 795442 Gasket Set-Engine
363 19069 Puller-Flywheel
365 691129 Screw (Carburetor)
383 19374s Wrench-Spark Plug
404 690272 Washer (Governor Crank)
425 690244 Screw (Air Cleaner Cover)
443 690255 Screw
(Air Cleaner Primer Base)
