HP ProLiant DL320 - Manual (Page 27)

Low-Profile 24X Max IDE Low-Profile 24X Max IDE Low-Profile 24X Max IDE Low-Profile 24X Max IDE
(ATAPI) CD-ROM Drive
(ATAPI) CD-ROM Drive (ATAPI) CD-ROM Drive (ATAPI) CD-ROM Drive
Disk Disk Disk Disk Applicable Disk CD-DA, CD-ROM
(Mode 1 and 2)
CD-XA, CD-I
(Mode 2, Form 1 and 2)
CD-I Ready, CD Extra, Video CD, CD-Bridge
Photo CD
(Single and Multi-session)
CD-WO
Capacity 550 MB (Mode 1, 12 cm)
640 MB (Mode 2, 12 cm)
Diameter 4.7 in, 3.15 in/12 cm, 8 cm
Rotational Speed 4200 rpm maximum
Center Hole 0.6 in/15 mm diameter
Thickness 1.2 mm
Track Pitch 1.6 µm
Block Size Block Size Block Size Block Size Mode 0 2,368, 2,352 bytes
Mode 1 2,352, 2,340, 2,336, 2,048 bytes
Mode 2 2,352, 2,340, 2,336, 2,048 bytes
Interface Interface Interface Interface IDE (ATAPI)
Access Times Access Times Access Times Access Times (typical) (typical) (typical) (typical) Random <150 ms
Full-Stroke <350 ms
Data Transfer Rate Data Transfer Rate Data Transfer Rate Data Transfer Rate Sustained 150 KB/s (sustained 1X)
Burst 2100 to 4800 KB/s
Cache Buffer Cache Buffer Cache Buffer Cache Buffer 128 KB
Start-up Time (typical) Start-up Time (typical) Start-up Time (typical) Start-up Time (typical) < 10 seconds
Stop Time Stop Time Stop Time Stop Time < 5 seconds
Operating Conditions Operating Conditions Operating Conditions Operating Conditions Temperature 41° to 118° F (5° to 45° C)
Humidity 10% to 80%
Dimensions Dimensions Dimensions Dimensions (HxWxD, maximum) 0.5 x 5.12 x 5.16 in (1.27 x 13 x 13.1 cm)
Weight <11.98 oz (<340 g)
QuickSpecs
HP ProLiant DL320 Generation 2 (G2) HP ProLiant DL320 Generation 2 (G2) HP ProLiant DL320 Generation 2 (G2) HP ProLiant DL320 Generation 2 (G2)
Technical Specifications
DA - 11512 North America — Version 30 — April 19, 2005 Page 27
