English –
33
MAINTENANCE
Service position for cutting unit
The cutting head can be placed in the service
position to provide easy access for cleaning, repairs
and servicing. In the service position the cutting unit
is raised and locked in the vertical position.
Placing in service position
1. Position the machine on flat ground. Apply the
parking brake (1). Adjust the cutting unit to the
lowest cutting height and lower the cutting unit.
P
1
2. Remove the front hood by removing the pin.
(There are complete instructions on using the
service position inside the front hood).
3. Remove the two support wheels from under the
front hood.
6017-218
6017-219
6017-220
