145
Figure 6-48 Snapshot
Please refer to the following sheet for detailed information.
Parameter Function
Channel It is the monitor channel.
Snapshot
mode
There are two modes: Timing and activation.
Frame rate You can select from the dropdown list. The value
ranges from 1f/s to 7f/s.
Resolution
You can select from the dropdown list.
For 16 series DVR:
1-Channel 1 and 9-channel support D1/CIF/QCIF.
Channel 2 to channel 8, channel 10 to channel 16
supports CIF/QCIF.
Quality
You can select from the dropdown list. Here is for
you to set video quality.
There are six options: 10％、30％、50％、60％、
80％、100％.
100% is the best quality.
