RGB ON SCREEN DISPLAY
86
USING THE RGB INPUT
VIDEO ADJUSTMENTS The following adjustments are independent of the TV mode:
•Press MENU in RGB mode for on screen display. Use the CURSOR PAD ̆ or ̄ to select VIDEO and
then press SELECT or CURSOR PAD ̈ to be inside the video menu
•Press CURSOR PAD ̆ or ̄ to highlight the item to be adjusted.
•Press SELECT or CURSOR PAD ̈ to select the highlighted item.
CONTRAST This feature allows you to adjust the contrast in RGB mode.
BRIGHTNESS
This feature allows you to adjust brightness in RGB Mode.
Use CURSOR PAD ̇ or ̈ to adjust contrast.
Press MENU button to return to RGB MODE
MENU and EXIT to quit.
NOTES: 1. Contrast can be set up to 110% if CURSOR PAD ̈ is pressed and held for more than 3 seconds.
2. See TV contrast feature for additional information regarding contrast.
Enhancer
Color Temperature
Brightness
Contrast
Video
Move SEL Select
Reset
High
Off
Reset
100%
50%
Enhancer
Color Temperature
Brightness
Contrast
Video
Move SEL Select
Reset
High
Off
Reset
100%
50%
Use CURSOR PAD ̇ or ̈ to adjust brightness.
Press MENU button to return to RGB MODE MENU
or EXIT to quit.
Enhancer
Color Temperature
Brightness
Contrast
Video
Move SEL Select
Reset
High
Off
Reset
100%
50%
Use the CURSOR PAD ̇ or ̈ to change the COLOR TEMPERATURE. Set to HIGH for a cooler
picture with more blue (1,200K), set to MEDIUM for more natural color (9,300K), or set to
STANDARD for accurate color (6,500K), or Black/White (5,400K).
COLOR
TEMPERATURE
Press MENU button to return to RGB MODE MENU
or EXIT to quit.
