16 Battery Charging light.
17 Image Display.
Camera front and bottom
1
6 4 5
2
3
1 Flash.
2 Self-Timer/Focus Assist light—See Using the Self-Timer settings on page 23 .
3 Microphone.
4 Tripod mount.
5 Dock connector.
6 Battery/Memory card door.
Camera dock and insert
When setting up the dock for use with this camera, install the dock insert that shipped in
the camera box. Attach the dock insert to the top of the camera dock by snapping it into
place.
2 3
1
Chapter 1
(continued)
6
