A.2
Pin Assignments
Pin D-Sub Connection
A P P E N D I X
PIN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Separate H/V
Red
Green
Blue
GND
GND (DDC Return)
GND-Red
GND-Green
GND-Blue
No Connection
GND-Sync/Self Test
GND
DDC-SDA
H_Sync
V_Sync
DDC-SCL
Composite H/V
Red
Green
Blue
GND
GND (DDC Return)
GND-Red
GND-Green
GND-Blue
No Connection
GND-Sync/Self Test
GND
DDC-SDA
H/V_Sync
Not used
DDC-SCL
