edge switch 2/32 installation guide B–5
Technical Specifications
Laser Information
Three configurations of cards with fixed optics will be provided for each of the
connector types: four extended long-wave ports, four long-wave ports, and four
short-wave ports.
Table B–7: Laser specs — 2 Gb
Shock and vibration
tolerance 60 Gs for 10 milliseconds without nonrecoverable errors
Acoustical noise 6.6 Bels
Inclination 10° maximum
Table B–6: Operating Tolerances (Continued)
Specification Value
Part Number
Transceivers
on UPM Card
Wave
Length Media/Distance Standard
300836-B21
Long wave
—
35 Km
4 Extended
Long wave 1310 nm 9/125 µm
Single-mode:
1 m–35 Km 100-SM-LL-L
300835-B21
Long wave
—
10 Km
4 Long wave 1310 nm 9/125 µm
Single-mode:
1 m–10 Km 100-SM-LL-L
300834-B21
Short wave 4 Short wave 850 nm 50/125 µm
Multimode:
2 m–500 m
62.5/125 µm
Multimode:
1 m–200 m
100-M5-SN-I
