HP Vectra VL 5/xxx Series 5 PC
Precautions When Replacing the Power Supply
Precautions When Replacing the Power Supply
Replacing the Processor Chip
System Board
The system board layout is shown on the next page.
Most desktop and minitower models are supplied with an S3 Trio 64 V2
video controller integrated on the system board. Models that are supplied
with a Matrox graphics controller on a PCI board do not have an integrated
graphics controller.
With the minitower package, always check the position of the voltage
selection switch.
If any thermal interface material, such as
aluminium foil or silicone, is supplied with
the heat-sink or the processor chip, place it
carefully on the top of the processor before
installing the heat-sink.
