ASSEMBLY STEP
NOTE: There is NO hardware bag for this step.
A) Carefully snap
TOP COVER into the MAIN FRAME.
B) Slide
CONSOLE MAST BOOT down over the TOP COVER.
MAIN FRAME
CONSOLE
MAST
BOOT
TOP COVER
