B.1 Network Interface Card
B-1
Spe
c
if
ic
at
ion
s
Ap
pen
dix
B
B.1 Network Interface Card
The following tables provide general specifications for the NIC.
Network Interface Card General Specifications
B.2 10/100BaseT/UTP Cables
Use the following universal Ethernet standard when configuring your
10/100BaseT/UTP cables to connect to the RJ45 connector on the NIC.
The cable should be Category 5.
Size: 125.00 mm length
×
95 mm height
Weight: 10Base T/2 : 3 10/16 oz. (102.5 g)
10/100 Base T: 3 3/16 oz. (89.5 g)
Environment: 0 to 50 degrees Centrigrade, 5% to
80% humidity
Controls and Indicators: One green LED and one amber LED
Configuration: Stored in non-volatile memory
Connectors: Ethernet: 8-wire RJ45 10/100BaseT or
BNC 10Base2
Pin Number Color Ethernet
8 blue/white
7 blue
6 orange/white Receive –
5 green/white
4 green
3 orange Receive +
2 brown/white Transmit –
1 brown Transmit +
