QuickSpecs
hp iPAQ Pocket PC h5400 Series
DA-11427 North America — Version 3 — January 7, 2003 5
Standard Features
Bluetooth Specifications* Technology high-speed, low-power, short-range
Bluetooth specification 1.1 compliant (2.4-GHz Industrial Scientific Medical Band)
System interface 921k high-speed UART processor interface
User Interface Bluetooth Manager
Operating system support Microsoft Pocket PC and Pocket PC 2002
Device type Class II device; up to 4 dBm transmit, typical 10 meter range
Power 3.3V ± 5% Peak current - typical TX current at approximately 140 mA
Receiver sensitivity –78 dBm or greater
Regulatory standards R&TT#-EN 300 328 and EN 300 826, UL 1950, CB Safety Scheme inclusive of
EN 60950 and IEC 950, FCC Part 15 subpart C, Canadian, CE,
Profile Support General Access Profile
Service Discovery Application Profile
Serial Port Profile
Generic Object Exchange Profile
File Transfer Profile
Dial-Up Networking Profile
LAN Access Profile
Object Push Profile
Personal Area Networking Profile
Basic Printing Profile
Hard Copy Replacement Profile (printing)
Usage Models *
Service Discovery
Determine what Bluetooth devices are within range and support authorization
File Transfer
File and directory browsing and navigation on another Bluetooth device.
File copying
Object manipulation – including add, delete, create new folders etc.
Serial Port
Synchronization between PDAs and PCs
Access Point
Wireless link to WAN thru cell phone
Agnostic to WAN technology
Send/receive SMS messages
Connect your printer and scanner to your personal network wirelessly
Adhoc Bluetooth Pico-networking (point to multi-point)
LAN Access
Wireless link to Corporate LAN using Bluetooth
Corporate email, network neighborhood, access to LAN applications, file transfer,
ftp, Internet browsing, etc, using TCP/IP
Access the Internet by connecting to your desktop or notebook over Bluetooth
nd using its network connection
Object Push
Exchange business cards, tasks, documents, appointments and more
Personal Area Networking
Collaborate, chat, play games, exchange data
Adhoc peer to peer networking
Basic Printing and Hard Copy Replacement Profiles
Print to any HP Bluetooth printer without the need for cables or specific print
rivers
Certifications All necessary regulatory approvals for countries we support including:
Bluetooth logo (FCC (47 CFR) Part 15C, Section 15.247&15.249 ETS 300 328,
ETS 300 826 Low Voltage Directive IEC950 UL and CE Mark
NOTE: * A standard WLAN infrastructure, other devices enabled with Bluetooth, and a service contract with a
wireless airtime provider may be required for applicable wireless communication. Wireless Internet use
requires a separately purchased service contract. Check with a service provider for availability and
coverage in your area. Not all web content available.
