21

Figure 8.
Straight Up Vertical Venting

STRAIGHT UP

VERTICAL VENTING

V (FT.)

40' MAX. (12.4 M)

STRAIGHT OUT

HORIZONTAL VENTING

H

Max. Run

24" (610 mm)

Figure 9.
Straight Out Horizontal Venting

H

V

CAP
