16
Figure 3. Diagram of the L & R CORNER-TRC
LEFT SIDE FRONT RIGHT SIDE
REAR VENT
COLLARS
ELECTRICAL
ACCESS
GAS LINE
ACCESS
GAS CONTROLS
& LABELS
BOTTOM
GRILLE
SIDE GLASS
DOOR
TOP GRILLE
END GLASS
DOOR
TOP STANDOFFS
TOP VENT
COLLARS
42 3/4 (1086mm)
13 (330mm)
VENT COLLARS
12 1/8 (308mm)
25 1/4 (642mm)
GAS LINE
ACCESS ELECTRICAL
ACCESS
2 1/2
(64mm)
2 /12/
(64mm)
4 (102mm) 4 (102mm)
36 1/8 (918mm)
40 3/4 (1034mm)
28 7/8
(733mm)
36 7/8 (937mm)
41 (1041mm)
24 1/4 (616mm)
